Competitive Price HY-X50W 40W 110V/220V Co2 Cutting Machines Laser Tube Power Supply
-
01
The digital display screen can show the current size, light output indication signal, water protection signal, and integrates potentiometer and manual current adjustment and test buttons.
The installation dimensions of the LCD screen and the pointer ammeter are consistent, making a perfect replacement.
-
02
The X series is externally connected to the display screen via standard network cables, while the XA series comes with a built-in LCD display screen. The exclusive and proprietary fault detection function enables customers to quickly identify laser tube or power supply faults with just one click on site without the need for any instruments, greatly facilitating users' self-inspection and repair.
Application fields
Leather cutting machines, garment cutting machines, shoe pattern cutting machines, advertising engraving machines, leather engraving machines, glass engraving machines, laser bag opening machines, laser drilling machines, laser marking machines, etc.
Product parameters
| Model | HY-X50/XA50 |
| Input Voltage | AC220V(110V can be customized) |
| Frequency | 47- 440HZ |
| Max Input Power | 250W |
| Max Input Current | 1A |
| Max Output Voltage | DC 25KV |
| Max Output Current | DC 20mA |
| Efficiency | ≥90%（full load) |
| MTBF | ≥10000 hours |
| Response Time | ≤1ms（The time from the given switch signal to the moment when the output current rises to 90% of the set current） |
| Withstand Voltage | Input - Output, Input - Shell: AC1500V 10MA for 60 seconds; The negative terminal of the output is connected to the shell. |
| Operation Environment | Working temperature (-10~40)°℃，Relative humidity :<90% |
| Cooling Method | forced air cooling |
| Matching laser tube power | 30-50W |
| Overall Dimension(L*W*H) | 194*158*90 |
| Weight (KG) | 1.7 |
| Color | BLACK |
FAQ
Q: Can I visit your factory?
Warmly welcome you to visit our factory!
Q: Are you a factory or a trading company?
We are a factory with export rights.
Q: What is your delivery time?
A: We have stock, normally our delivery time is within 10 days after confirmation.
Q: How can I get a quote?
A: Please leave us a message stating your purchase requirements and we will get back to you immediately. You can also contact us directly via WhatsApp or any other convenient instant messaging tool
Q: What is the MOQ?
A: Our MOQ is 1 piece
Q: What is the payment method?
A: For single products, we support 100% T/T payment and ship within 7 days.
For large custom orders, we accept T/T (30% as deposit, 70% as copy of bill of lading) and other payment methods.
We also support Alibaba Assurance
Q: Can you provide warranty for your products?
A: Yes, we provide a 1year limited warranty.
Q: Do you need local agents?
A: Yes, we support local agents who represent our brands. We will give agents very favorable purchase prices and protect the interests of local agents in pricing.
